Kraun Wireless ADSL2/2plus Modem Router 54Mbps User Manual page 18

will terminate
automatically. If a connection request
is received from the local network the
device automatically establish a dial-
up connection.
c. PPP IP extension:
When the device is connected with a
computer, the IP address obtained
through the upstream link is directly
allocated to this computer connecting
with the device. After the PPP IP
extension is enabled, you can enable
the advanced DMZ. At this time, you
need to enter your DMZ host and
subnet mask.
d. Use Static IP Address:
After this option is checked, the device
uses this IP address as the WAB IP
address and does not need to obtain it
through the upstream link.
e. Retry PPP password on authentication
error.
f. Enable PPP debugging mode.
3) Click "Next" to display the window shown
on the right.
b. Enable IGMP Multicast: IGMP agent.
To enable IPTV in the PPPoE mode,
you need to check this option.
c. Enable WAN Service: Checked by
default. It is recommended to keep this
default setting, unless you do not need
to activate your WAN.
d. Click "Next" to display the window
shown on the right. This window lists
your settings.
4) Click "Save/Reboot" to activate your
settings.
Wireless ADSL2/2+ Modem Router 54Mbps
the connection
18 www.kraun.it
