Mac Address Filtering - Kraun Wireless ADSL2/2plus Modem Router 54Mbps User Manual

4.4.2.6 If "Network Authentication" is set as
"Mixed WPA2/WPA", the system displays
the window shown in the right figure.
(1) WPA2 Pre-authentication: Enabled,
Disabled
Network Re-auth Interval
(2) WPA Group Rekey Interval
(3) RADIUS Server IP Address: IP
address of the target server of
802.1X authentication
(4) RADIUS Port: Port number of the
target server of 802.1X
authentication
(5) RADIUS Key
(6) WPA Encryption: TKIP, AES,
TKIP+AES
(7) WEP Encryption: Enabled, Disabled
4.4.2.7 If "Network Authentication" is set as
"Mixed WPA2/WPA-PSK", the system
displays the window shown in the right
figure.
1) WPA Pre-Shared Key
2) WPA Group Rekey Interval: Once
this interval times out, the key will
change. If this value is set to 0, the
key will not change.
3) WPA Encryption: TKIP, AES,
TKIP+AES
4) WEP Encryption: Enabled, Disabled

4.4.3. MAC address filtering

4.4.3.1 Click "MAC Filter" to display the
window shown in the right figure.
MAC Restrict Mode: Disabled, Allow, Deny.
Here you may add/delete devices to either
allow of deny access to the network.
4.4.3.2 Click "Add" to display the window
shown in the right figure. MAC
Address: Enter the MAC address to
be controlled.
Click "Save/Apply".
Wireless ADSL2/2+ Modem Router 54Mbps
36 www.kraun.it
