Kraun Wireless ADSL2/2plus Modem Router 54Mbps User Manual page 20

5) Use the following DNS server address:
To manually enter a DNS address, check
this option and enter the IP addresses of:
a. Primary DNS server
b. Secondary DNS server
6) Click "Next".
a. Enable IGMP Multicast:
IGMP agent. For example, to enable
the IPTV in the PPPoE mode, you
need to check this option.
b. Enable WAN Service:
Checked by
recommended to keep this default
setting, unless you do not need to
activate your WAN.
7) Click "Next" to display the window shown
in the right figure. This window lists your
settings.
8) Click "Save/Reboot" to activate your
settings.
IPoA mode.
1) Select "IP over ATM (IPoA)".
Encapsulation Mode: VC/MUX
LLC/SNAP-ROUTING
Once you select a mode, the system
automatically changes the encapsulation
mode into the one matching your setting.
Therefore, it is recommended to keep the
default setting unchanged.
Wireless ADSL2/2+ Modem Router 54Mbps
default. It is
20 www.kraun.it
