Kraun Wireless ADSL2/2plus Modem Router 54Mbps User Manual page 28

e. Source Port: Enter the port number of
the external network IP address to be
filtered.
f. Destination IP address: Enter the
internal network IP address to be
filtered.
h. Destination Subnet Mask: Enter the
subnet mask corresponding to the
internal network IP address to be
filtered.
i. Destination Port: Enter the port
number of the internal network IP
address to be filtered.
Based on the above settings, you can
add your filtering rules.
You may select your WAN interface.
However, it is recommended to keep the
default setting unchanged.
5) Click "Save/Apply".
4.2.4.2. Parental control
1) Click "Time of Day Restriction" to display
the window shown in the right figure.
2) Click "Add" to display the window shown
in the right figure. Here, you can set a
specific period to restrict Internet access
of a MAC address.
3) Click "Save/Apply".
Wireless ADSL2/2+ Modem Router 54Mbps
28 www.kraun.it
