3) Click "Next" to display the window shown
in the right figure.
a. Enable IGMP Multicast: IGMP agent.
To enable the IPTV in the PPPoE
mode, you need to check this option.
b. Enable WAN Service: Checked by
default. It is recommended to keep this
default setting, unless you do not need
to activate your WAN.
4) Click "Next" to display the window shown
in the right figure. This window lists your
settings.
5) Click "Save/Reboot" to activate your
settings.
PPPoE Mode.
1) Select "PPP over Ethernet (PPPoE)".
Encapsulation Mode:
VC/MUX/LLC/SNAP-BRIDGING
Once you select a mode, the system
automatically changes the encapsulation
mode into the one matching your setting.
Therefore, it is recommended to keep the
default setting unchanged.
2) Click "Next" to display the window shown
in the right figure.
a. Authentication Method:
AUTO/PAP/CHAP/MSCHAP.
Usually, "AUTO" is selected.
b. Dial on demand:
If you check this option, you need to
manually enter the timeout time. If no
communication is detected when the
timeout setting is reached, the device
