Kraun Wireless ADSL2/2plus Modem Router 54Mbps User Manual page 22

e. Click "Next" to display the window
shown in the right figure. This window
lists your settings.
5. Click "Save/Reboot" to activate your
settings.
Bridging mode.
1) Select "Bridging".
Encapsulation Mode:
VC/MUX/LLC/SNAP-BRIDGING
Once you select a mode, the system
automatically changes the encapsulation
mode into the one matching your setting.
Therefore, it is recommended to keep the
default setting unchanged.
2) Enable Bridge Service:
To select the bridge mode, you need to
check this option. By default, this option
is checked.
3) Click "Next" to display the window shown
in the right figure. This window lists your
settings.
4) Click "Save/Reboot" to activate your
settings.
Wireless ADSL2/2+ Modem Router 54Mbps
22 www.kraun.it
