Chapter 4. Configuration Description

4.1 Device information

Select "Device Information" -> "Summary"
to display the current system information.
4.1.1 The Device Information shows:
- Hardware version
- Software version
- Boot version
- Wireless driver version
- LAN MAC address
- WAN MAC address
- Running time
- System time
4.1.2 The DSL information shows:
- Upstream link rate
- Downstream link rate
- LAN IP address
- Default gateway: In the pure bridge
mode, there is no gateway; in other
modes such as PPPoE and PPPoA, the
gateway address is the IP address of the
upstream device.
- Primary DNS server: In the
PPPoA/PPPoE mode, the DNS address
is obtained from the upstream device; in
the pure bridge mode, it is not required to
set the DNS address; in other modes,
you can manually enter the DNS
address.
- Secondary DNS server
4.1.3 Click "WAN" to display the WAN
connection status and settings.
4.1.4 Click "Route" to display the window
shown in the right figure, displaying the
default information.
