Kraun Wireless ADSL2/2plus Modem Router 54Mbps User Manual page 24

2) Click "Add" to display the window
shown in the right figure.
a. Select a Service: Selecting the service
to be enabled.
b. Custom Server: Manually enter the
server name.
c. Server IP Address: LAN IP address for
the server.
NOTE: After a well-known service is
selected, the system automatically opens
the corresponding port. After manually
entering a customized service, you need to
manually enter the port to be opened.
d. Click "Save/Apply" to display
service added, as shown in the right
figure.
4.2.3.2 Port triggering
1) Click "Port Triggering" to display the
window shown in the right figure. Here, you
can add or delete your port triggering
service settings.
For some special applications, you need to
enable some ports
application to function.
triggering, you can automatically enable the
ports as required by a particular application.
2) Click "Add" to display the window shown
in the right figure.
a. Select an application: Select the name
of the service to be enabled.
b. Custom application: Manually enter
the service name.
Wireless ADSL2/2+ Modem Router 54Mbps
the
required by the
Through port
24 www.kraun.it
