4.2.7

DSL

Click "DSL" to display the window shown in
the right figure.
Here you may enable a service as required.
By default, the system checks the status of
G.dmt, G.lite, T1.413, ADSL2, ADSL2+,
READSL2, Bitswap and SRA services. The
device can automatically negotiate with the
upstream device.
4.2.8

Port mapping

4.2.8.1 Click "Port Mapping" to display the
window shown in the right figure.
4.2.8.2 Enable virtual ports on: Select or
clear it.
Port mapping supports the mapping from
multiple ports to PVC and bridging group.
Each group will serve as an independent
network.
4.2.8.3 Click "Add" to display the window
shown in the right figure.
Group Name: Customizing a name.
Select the interface to be added into
the group and click "Add".
To automatically add a LAN client to
the PVC of a new group, you need
to add the ID character string of a
DHCP provider. After configuring
the ID character string for the DHCP
provider, the
customer with the specified provider
ID (DHCP as "60") from the IP
address from the local DHCP server
will be rejected.
NOTE: The client possibly obtains the IP
address of the public network. In this case,
the selected interface is removed from the
existing groups and added into a new
group.
