Lan; Nat - Kraun Wireless ADSL2/2plus Modem Router 54Mbps User Manual

4.2.2 LAN

4.2.2.1 IP Address:
IP address used by the router to connect to
the LAN. This option is set to 192.168.0.1
upon device delivery. You may change it as
required.
NOTE: After changing this IP address, you
need to use the new IP address to access
the WEB management window when next
accessing the Web interface of the router.
In addition, you must set the default
gateway for each computer in your LAN to
this IP address, to ensure normal Internet
access.
4.2.2.2 Subnet Mask:
Enter the Subnet Mask.
4.2.2.3 Enable IGMP Snooping:
Used in Bridging Mode.
4.2.2.4 Standard Mode
4.2.2.5 Blocking Mode
Configure the second IP Address and
Subnet Mask for LAN interface.
Click "Save/Reboot" to save and activate
the new settings.

4.2.3 NAT

4.2.3.1 Virtual server
1) Click "NAT" → "Virtual Server" to display
the window shown in the right figure. Here,
you can add or delete your virtual server
settings.
By default, the external networks cannot
access the IP address of your internal
network. However, if you need such access
by the external networks (for example, you
need to set up the server or support some
special applications), you should enable
this function to allow the access by external
networks.
Wireless ADSL2/2+ Modem Router 54Mbps
23 www.kraun.it
