4.2 Advanced settings

4.2.1 WAN

Select "WAN Settings' from the Advanced
Settings Tab in the left hand menu. If the
WAN information has been set, you may
edit the information in this window, or add
new information.
NOTE: After modifying or adding new
information, you need to reboot the device
to activate the setting.
1. VPI (Virtual
Virtual path between two points in
the ATM network.
Value ranges 0 - 255.
2. VCI (Virtual Channel Identifier):
Virtual channel
points in the ATM network. Value
range 32 - 65535 (1 - 31 are
reserved
protocols).
3. Service category: Select one
from five
categories.
4. Enable Quality of Service (QoS):
Allows you to enable or disable
QoS.
a. You may enable the VLAN
Mux and QoS. After the VLAN
Mux is enabled, the window
shown in the right figure is
displayed. You may modify the
VLAN ID here.
b. NOTE: When you click "Next"
after enabling the VLAN Mux,
the window shown in the right
figure is displayed, because
the 802.1
supported only in the PPPoE,
MER and bridge modes.
Wireless ADSL2/2+ Modem Router 54Mbps
Path Identifier):
between two
for well-known
available service
VLAN flag is
