Wireless ADSL2/2+ Modem Router 54Mbps
3.2.2 Click "Next". Enter the PPP User
name and Password provided by your ISP.
If the ISP also provides the PPPoA service
name, enter the corresponding value or
otherwise, leave this field blank. Use the
default values for other options. Refer to
the advanced settings section for details of
these settings.
3.2.3 Click "Next" and enable the WAN
service (it is enabled by default).
3.2.4 Click "Next" to display the window
listing your settings for confirmation.
3.2.5 Click "Save/Reboot" to activate your
settings. The system will reboot and
automatically re-connect in about 2
minutes. A progress window similar to the
shown on the right will appear during the
reboot cycle.
10 www.kraun.it
