PPPoA Mode.
1) Select "PPP over ATM (PPPoA)".
Encapsulation Mode: VC/MUX/LLC
Once you select a mode, the system
automatically changes the encapsulation
mode into the one matching your setting.
Therefore, it is recommended to keep the
default setting unchanged.
2) Click "Next" to display the window shown
in the right figure.
a. Authentication Method:
AUTO/PAP/CHAP/MSCHAP.
Usually, "AUTO" is selected.
b. Dial on demand:
If you check this option, you need to
manually enter the timeout time. If no
communication is detected when the
timeout setting is reached, the device
will terminate
automatically. If a connection request
is received from the local network the
device automatically establish a dial-
up connection.
If this option is disabled, the device is
always in online status until the device
is powered off or a connection failure
or other system failures occurs.
c. PPP IP extension:
When the integrated
connected with a computer, the IP
address obtained
upstream link is directly allocated to
this computer connecting with the
device. After the PPP IP extension is
enabled, you can enable the advanced
DMZ. At this time, you need to enter
your DMZ host and subnet mask.
d. Use Static IP Address:
After this option is checked, the device
uses this IP address as the WAB IP
address and does not need to obtain it
through the upstream link.
e. Retry PPP password on authentication
error
f. Enable PPP debugging mode
Wireless ADSL2/2+ Modem Router 54Mbps
the connection
gateway is
through the
