Digital Projection morpheus 7000hdi User Manual

High brightness digital video projector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Morpheus 7000HDi
High Brightness Digital Video Projector

USER MANUAL

107-023A
106-744A
DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 0.64:1 fi xed
106-745A
DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 0.96:1 fi xed
106-746A
DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 1.2-1.44:1
106-747A
DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 1.44-1.8:1
106-748A
DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 1.8-2.4:1
106-749A
DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 2.4-3.6:1
106-750A
DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 3.6-5.6:1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the morpheus 7000hdi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digital Projection morpheus 7000hdi

Summary of Contents for Digital Projection morpheus 7000hdi

  • Page 1: User Manual

    Morpheus 7000HDi High Brightness Digital Video Projector USER MANUAL 106-744A DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 0.64:1 fi xed 106-745A DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 0.96:1 fi xed 106-746A DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 1.2-1.44:1 106-747A DLP 3-CHIP HD2 DC3 DUAL 300W PROJ 1.44-1.8:1...

  • Page 2: Declaration Of Conformity

    73/23/EEC Low Voltage Equipment Directive, amended by 93/68/EEC. Products covered by this Directive Large Screen Projector type Morpheus 7000HDi Basis on which Conformity is being declared The products identifi ed above comply with the protection requirements of the above EU...

  • Page 3: Table Of Contents

    INDEX Declaration of Conformity INDEX 1. CAUTION 2. MAINTENANCE Air Filter Replacement 3. INTRODUCTION 4. CONNECTION Input / Output Connection 5. LED and NETWORK LED Indication Network LAN Features 6. POWER SEQUENCING Applying power Powering Up Powering Down Quick Power Down 7.

  • Page 4: Caution

    1. CAUTION Canada This Class B digital apparatus complies with Canadian ICES-003.Cet appareil numérique de la classe CAUTION B est conforme à la norme NMB-003 du Canada. RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, Read before operating equipment.

  • Page 5: Maintenance

    1. CAUTION 2. MAINTENANCE Unpacking Save the original shipping carton and packing material. When you need to ship the product. The original packing carton can provide the maximum protection. The air fi lters is to prevent dust from entering the projector and to keep good air circulation. NOTE: Be sure to contact the dealer each 100 hours about the replacement of the air fi...

  • Page 6: Introduction

    3. INTRODUCTION 4.CONNECTION STATUS LEDs This Projector is a three-chip DLP projector with a native resolution of 1280x720 pixels (16:9 aspect ratio). The projector accepts 720p video through a DVI-D connector on the rear panel. RJ-45 EXTERNAL DVI-D RS-232 (SERIAL) SOFT SHUTTER LAMP DOOR...

  • Page 7: Led And Network

    5.LED's and NETWORK 6. POWER SEQUENCING LEDs Applying power • POWER STATUS When the power is fi rst applied, the projector comes up in STANDBY mode. It may be left in this state : Standby indefi nitely. Both controllers and the RS-232 circuitry are powered so that the unit can respond to serial : Power On or Power-up sequence commands, the IR Remote Control or the rear panel switch.

  • Page 8: Quick Power Down

    7. STATUS LED's Quick Power down If the projector is in the 5 MINUTE POWER DOWN sequence, pressing the SOFT POWER switch again (1/2 second or more) will initiate the 60 SECOND POWER OFF sequence. To cancel 5 MINUTE POWER DOWN press the SHUTTER switch. OR If the IR remote is enabled - press the OPEN button on the remote control which will open the SHUTTER and cancel the 5 MINUTE POWER DOWN.

  • Page 9: Infrared Remote Control

    8. INFRARED REMOTE CONTROL FUNCTIONS Power Power on or Power off the projector Focus Far , Focus Near Adjust the image focus White Level Changes the Gain or Contrast of the picture. Which affects the white parts of the image Open, Close Power Black Level...

  • Page 10: Specifications

    9. SPECIFICATIONS Status Status Monitoring LED Array Green/Off Control Board Power Feature / Attribute Description Fans Valid Signal Input Lamp ON Optics Shutter Open Contrast 1800 to 1 nominal DMD Formatter ON Ballast Temperture OK Uniformity >85% System Ready Resolution 3 chip DLP 720p (1280 x 720) 48Hz, 50Hz, 60Hz Lamp 2 x 300W lamp...

  • Page 11: Dimensions

    10. DIMENSIONS 653.0 482.5 19.05 Dimensions in mm...
