External Connectors

Rear I/O Panel
Connector
USB
LAN
COM1
COM2
MS/KB
DVI
Audio
QDSP-2020 User's Manual
Chapter 5
Interface
Function
USB2.0 Type A Connector
10/100/1000 Ethernet RJ-45 Connector
RS-232/422/485 Port DB-9 Connector
RS-232 Port DB-9 Connector
PS/2 KB/MS Mini-DIN Connector
DVI-I Connector
Audio IN, Audio Out, MIC

Table 2 Rear panel connectors description

Table 3 USB2.0 Type A connector (USB)

24
