802.1X/Radius Configuration

802.1x is an IEEE authentication specification that allows a client to connect to a wireless
access point or wired switch but prevents the client from gaining access to the Internet
until it provides authority, like a user name and password that are verified by a separate
server.

System Configuration

After enabling the IEEE 802.1X function, you can configure the parameters of this
function.
1. IEEE 802.1x Protocol: enable or disable 802.1x protocol.
2. Radius Server IP Address: set the Radius Server IP Address.
3. Server Port: set the UDP destination port for authentication requests to the specified
Radius Server.
4. Accounting Port: set the UDP destination port for accounting requests to the
specified Radius Server.
5. Shared Key: set an encryption key for using during authentication sessions with the
specified radius server. This key must match the encryption key used on the Radius
Server.
6. NAS, Identifier: set the identifier for the radius client.
7. Select .
65
