2. Hardware Description

This section describes the hardware of the CWGE2FE24MODMS switch, and gives a

physical and functional overview of the switch.

The CWGE2FE24MODMS switch has a physical dimension of 440mm(W) x 280mm(D) x

44mm(H).

The Front Panel of the CWGE2FE24MODMS switch supports 2 kinds of port modules.

Please refer to the module user guide for further information.
