Introduction

The CWFE8TX8MS Managed Ethernet Switch is a compact size switch that is
an ideal solution for industrial applications. It provides a Fast Ethernet
switching function that allows for high-performance, low-cost network
performance. The CWFE8TX8MS features a store-and-forward switching and
can auto-learn and store source addresses on an 8K-entry MAC address
table.
The CWFE8TX8MS provides 8 switched auto-sensing 10/100 Mbps RJ45
Ethernet ports. The switch will automatically detect the speed of the device
that you plug into it to allow you to use both 10 and 100Mbps devices. The
10Mbps bandwidth will accommodate 10Mbps workgroup hubs while
simultaneously providing the 100Mbps bandwidth needed to accommodate
multimedia applications. In addition, each RJ45 port supports the Auto
MDI/MDIX function.
With built-in web-based management, managing and configuring the
CWFE8TX8MS becomes easier. The user can visually configure and manage
the network via Web Browser. Just click the mouse instead of typing
command strings. However, the CWFE8TX8MS can also be managed via
Telnet, Console, or SNMP Management.
