Physical and operating specifications
This chapter provides physical and operating specifications for the HP ProLiant DL180 G6 server.
Specifications include:
System unit
Table 29
Hardware Specifications
Item
Processor socket
Processor
Chipset
Hardware monitoring device
Gigabit ethernet controller
Onboard storage controller
ODD & Floppy interface
Embedded video controller
I/O subsystem
Memory
Default media storage
Optical disc drive
I/O ports
Components
Intel FCLGA1366 socket
2P Intel Xeon processor 5500 series with integrated memory
controller
2P Intel Xeon processor 5600 series with integrated memory
controller
Tylersberg-36D/ICH-10R
ServerEngines Pilot 2 management controller
HP NC362i GbE controller for NIC
LO100i sideband support
Integrated ICH10R SATA (6-port)
Optional Optical Disc Drive (SATA)
Optional Floppy (USB only, USB key)
ServerEngines Pilot 2 management controller
One PCIe x16 links with x16 slot + PCIe x4 links with x4 slot
One PCIe x16 links with x16 slot
Twelve DDR3 800/1066/1333 MHz RDIMM/UDIMM slots, up to
96 GB
Four bays hot-plug HDD cage for 3.5" SAS or SATA drivers
Eight bays hot-plug HDD cage for 3.5" SAS or SATA drives
Eight bays hot-plug HDD cage for 2.5" SAS or SATA drives
Twelve bays hot-plug HDD cage for 3.5" SAS or SATA drives
Twenty-five bays hot-plug HDD cage for 2.5" SAS or SATA drives
One slim optical disc drive bay for optical disc drive on the front (8
3.5" HDD model)
PS/2 keyboard port, PS/2 mouse port, USB 2.0 ports (two rear
USB ports, one internal USB port, two front USB ports), video port,
serial port and GbE port and IPMI LAN port.
Physical and operating specifications 152
