UM1011
Press any joystick push-button to display the next help slide as shown in

Figure 63. Second Help slide

Press the joystick to exit the slide and return to the Help submenu
If you choose Jumpers config, a list of jumpers to be configured for the demonstration is
displayed on the LCD screen. Use Right and Left to go to the next jumper configuration. If
you press the Down push-button, you return to the Help submenu.
2.7.10

About submenu

This submenu shows the version of the STM32F100ZET6 demonstration software. When
the About submenu is selected, the message shown in
screen.

Figure 64. About submenu

Press SEL to display a message showing the STM32100E-EVAL demonstration version on
the LCD screen.
UP, DOWN, RIGHT and
LEFT push-buttons
perform circular
navigation in the
main menu, current
menu items. SEL
push-button selects
the current item. UP
and DOWN perform
vertical navigation
About
About
Return
Doc ID 18064 Rev 1
Running the demonstration
Figure
(Figure 61).
Figure 64 is displayed on the LCD
63.
43/49
