Running the demonstration
Normally, for the Standby command, the device is in Stop mode and can wake up only when
it receives a new command. However, you can use the TAMPER push-button to exit the
HDMI-CEC submenu in case the demonstration is blocked.
Any time in the CEC application, if you press the TAMPER push-button, the HDMI CEC
stops and you return to the HDMI CEC submenu shown in
Note: The STM32100E CEC device responds only to the following commands. To other
commands, it sends a feature abort.
●
Standby
●
Get CEC version
●
Give physical address
●
Give OSD name
2.7.9

Help submenu

This submenu provides help on the various keys used in the STM32F100ZET6
demonstration. When this submenu is selected, the message shown in
displayed on the LCD screen.

Figure 61. Help submenu

If the user chooses the menu navigation, the image shown in
LCD screen.

Figure 62. Joystick push-buttons

42/49
Help
Menu Navigation
Jumpers Config
Return
Doc ID 18064 Rev 1
Figure 56.
Figure 61
Figure 62 is displayed on the
UM1011
is
