UM1011

Figure 22. Setting the time and date

You have the choice to set or not the time, year, month and day. Press any key (except for
SEL) to ignore the prompt and abort the configuration sequence. Press on SEL and follow
the setting sequence to set the time and date.
Time submenu
This submenu is divided into two items that allow you to display or set the current time:
●
Time Adjust: after powering up the evaluation board, you can use this submenu to
change the default time (00:00:00) to the current time.
To adjust the time:
1. Select Time Adjust. The message shown in
modify the first digit of the hour field, use the UP and DOWN push-buttons. Press UP to
display the current value plus one. Press DOWN to display the previous digit value.
2. After setting the digit value, press SEL. The cursor automatically jumps to the next digit.
When all the time digits have been set, the Time submenu appears. Some digit values are
limited to a range of values depending on the field (hour, minutes or seconds).

Figure 23. Time Adjust submenu

●
Time Show: this item displays the current time. If time and date have not been
previously configured, a message is displayed, prompting the user to set the time and
date or to exit to the upper submenu. When this submenu is selected, the message
shown in Figure 24 appears on the LCD. In the example, the time has not been set yet.
Doc ID 18064 Rev 1
Running the demonstration
Figure 23 is displayed on the LCD. To
25/49
