Uploading HTML files

You can create customized HTML pages for the SMX to display. The HTML Files List window
(see figure 43) provides a way to view the contents of the SMX file system and to upload
custom HTML pages to the SMX.
Figure 43.
HTML Files List Window
Upload HTML pages as follows:
NOTES: • The files listed in the figure 43 are shown for example only and may not be
present on your switcher.
• The HTML Files List window is for inserting your own HTML pages. This is not
the window to replace the firmware that controls all switcher operation. To
replace the firmware (see
• The following characters are invalid or not recommended in file names:
A = ' [ ] { } < > ` " " ; : | \ ?
1.
Connect the PC to the SMX via the switcher RS-232/RS-422 port or Ethernet port.
2. Start the SMX Control Program and connect to the SMX (see
page 62 for the procedure).
3.
From the menu, select
Tools
4. Click the
Pick File(s) to Load to Server
5.
Navigate to the folder where you saved the HTML files. Select the files.
NOTES:
• To select multiple files, hold the
• If you want one of the HTML files that you created to be the default
start-up page, name the file "index.html." The SMX automatically looks
for that file name when first connecting to it using an Internet browser.
6.
Click the button. The file uploading process may take a few minutes.
Open
7.
Click the Update button to confirm the upload.
8. Click the button to exit the HTML Files List window.
Close
Update firmware
HTML File Manager
button. The Select files window opens.
Ctrl key while clicking the desired files.
SMX System MultiMatrix Switcher • SMX Control Software
on page 83).
and
space
Using the Program
. The HTML Files List window opens.
+ ~ ,
on
85
