Extron electronics SMX System User Manual page 88

Setting the mail server IP address
The
Mail Server IP Address
the e-mail for the facility in which the SMX switcher is installed.
Valid IP addresses consist of four 1-, 2-, or 3-digit numeric subfields separated by dots
(periods). Each field can be numbered from 000 through 255. Leading zeros, up to 3 digits
total per field, are optional. Values of 256 and above are invalid.
Edit this field as follows:
1.
Click in the
Mail Server IP Address
2.
Make any desired changes to the mail server IP address.
3. Press the key on the keyboard or click in another field to exit the
Tab
field
Address
4. Click the button to make the address change take effect.
Take
Setting the mail server domain name
The Mail Server Domain Name
on to the e-mail server. Standard domain conventions (such as
NOTE:
The following characters are invalid or not recommended in a domain name:
~ , @ = ` [ ] { } < > ' " " ; : | \ ?
acceptable only as the lead-in to the domain name (such as
Edit this field as follows:
1. Click in the
Mail Server Domain Name
cursor.
2.
Edit the name as desired.
3.
Press the key on the keyboard or click in another field to exit the
Tab
Domain Name field.
4. Click the button to make the name change take effect.
Take
Entering e-mail addressee information
The eight
E-mail Addressee
addresses of the personnel to whom the SMX e-mails notification of its failure and repair
figure 41
status (see for a typical e-mail message from the SMX).
Figure 41. Typical SMX E-mail
The radio buttons and check boxes associated with each address field permit the
administrator to specify e-mail requirements for each recipient.
Edit these fields and controls as follows:
1. Click in the desired
E-mail Addressee
2.
Edit the e-mail address as desired. Standard e-mail address conventions (such as
nnnnn@xxx.com ) apply.
3. Press the key on the keyboard or click in another field to exit the
Tab
field.
addressee
field displays the IP address of the mail server that handles
field. The graphic cursor becomes a text cursor.
field displays the domain name that the SMX uses to log
field. The graphic cursor becomes a text
fields permit the administrator to identify the e-mail
field. The graphic cursor becomes a text cursor.
SMX System MultiMatrix Switcher • SMX Control Software
Mail Server IP
) apply.
nnnnn@xxx.com
and . The @ character is
space
@folklore.net
Mail Server
e-mail
+
).
82
