Windows buttons, menus, and trash can
The buttons, drop-down lists, and trash can on the right side of the program
window perform the following functions:
Power
— This button is unavailable for SMX switchers, because the SMX
cannot be powered on and off via software.
Executive mode
— Locks out front panel operations, except for the view-
only mode functions.
menu — Displays a list of up to 32 global presets and up to 10
Presets
plane presets. From this list you can select a global or plane preset to display in
the window, then either activate the selected preset by clicking
by clicking
.
Delete
— Activates the selected preset as the current configuration.
Go
— Saves the current set of ties as a global or plane preset. Enter a
Save as
preset number for it when prompted to do so.
— Deletes the selected global or plane preset to be deleted.
Delete
— Saves to file any changes made to the displayed configuration.
Take
Cancel
— Returns to the previous screen, undoing any changes you have
made.
Trash can
— Drag and drop from an input or output button to the trash can
to undo all ties associated with that input or output.
SMX System MultiMatrix Switcher • SMX Control Software
or delete it
Go
86
