3. Operation
3.1 Preparation
3.1.1 Quick Setup
Quick Setup
1. Remove the two packing clips that hold the extruder head
packing clips that hold the extruder head
and platform in place during shipping.
and platform in place during shipping.
2. Attach the "roll holder
roll holder / feeder guide" onto the left side
of the printer using the middle sized included alan key.
using the middle sized included alan key.
Remove screw (b) and attach the roll holder as per
Remove screw (b) and attach the roll holder as per
diagram and attach with screw (b)
diagram and attach with screw (b)
3. Open the foil bag that contains
Open the foil bag that contains the ABS filament.
UP Plus 3D Printer User Manual
3D Printer User Manual
NOTE:
Do not let go of the end of the filament,
Do not let go of the end of the filament,
otherwise it will unravel
unravel itself and tie itself in a knot,
which will then cause a block in the extruder head and
which will then cause a block in the extruder head and
several hours of unwinding the spool manually to find
several hours of unwinding the spool manually to find
the knot!
v 2013.1.31
.1.31
