Figure 79 System / Network Setup Parameters-Large Display Only System - Emerson Liebert Challenger 3000 User Manual

Configuration Safe—This parameter saves or loads configuration settings for the display that have
been modified from the factory defaults to an internal file that can be downloaded / uploaded using
the Liebert iCOM Service Tool. Selecting "Save" will write the settings to the internal storage file and
selecting "Load" will write the settings from the internal storage file to the application software. The
internal file is updated every 12 hours automatically.
Network Safe—This parameter saves or loads network settings for the display that have been modi-
fied from the factory defaults to an internal file that can be downloaded / uploaded using the Liebert
iCOM Service Tool. Selecting "Save" will write the settings to the internal storage file and selecting
"Load" will write the settings from the internal storage file to the application software.
SW Version—This parameter contains the application software version loaded onto the Liebert
iCOM display.
Figure 79 System / network setup parameters—large display only System - Page 2
SYSTEM/NETWORK SETUP (page 2 of 2)
S812
S813
S814
S815
S816
S817
S818
S819
S820
S821
S822
Attention: any changes done on these parameters
must be followed by a 'Save+Reboot' command.
IP Address—This parameter contains the network address of the display. This address must be
unique to every other device on the network.
Netmask—Not currently used.
Gateway—Not currently used.
MAC—The MAC address is a unique hardware identifier of the Ethernet device.
U2U Protocol—This parameter is always set to GBP.
U2U Address—This parameter is a unique identifier for each unit on the network. Display addresses
range from 33 to 64. Each display on the U2U network must have a different U2U address.
U2U Group—This parameter is used to create zones or groups within a U2U network. Once a group
number is selected the display will only see other devices with the same group number. The group
number can be changed to view other devices in different groups.
Bootloader Variables—This parameter indicates if there has been a change to the bootloader since
it was last loaded. This parameter should only be activated by an authorized service person.
PASSWORD (Actual Level 3)
IP Address
Netmask
Gateway
MAC
U2U Protocol
U2U Address
U2U Group
Bootloader Variables
SYSTEM
192 .168.254.003
255 .255.255.000
0:000:000:000
00:00:68:1E:4A:A5
Changed
87
Service Menu Parameters
????
GBP
33
1
No
