Table 2 User menu icons (continued)
Icon
1 2
9 3
6
DO

Figure 10 Service menu icons

Table 3

Service menu icons

Icon
°C / °F
% RH
SET
WELLNESS
SERVICE
SET
ALARMS
Name
Description
Allows setback settings for non-peak
Sleep Mode
operation
Contains key contact information for local
Service Contact Info
service, including names and phone numbers
Change settings for Liebert iCOM Discrete
iCOM-DO
Output card
Name
Description
Setpoints To view and change temperature and humidity setpoints
Shows all entered program changes and maintenance
Unit Diary
performed on the unit
Standby Settings/
Allows lead/lag setup when multiple units are connected
Lead-Lag
Allows setting maintenance interval reminder,
Maintenance/
maintenance message, number of unit starts and stops,
Wellness Settings
and time since last maintenance
Diagnostics/ Allows troubleshooting, manual mode, read analog and
Service Mode digital inputs
Set Alarms Allows enable, disable and settings for alarms
Liebert iCOM Display Components and Functions
DO
10
Available On Display
Small & Large
Small & Large
Small & Large
Service Menu password: 5010
Available On
Display
Small & large
Large
Small & large
Small & large
Small & large
Small & large
