Figure 72 iCOM-DO Overview and Override - Page 1
iCOM-DO Overview and Override (pg 1 of 3)
S720
S721
S722
S723
S724
S725
S726
S727
S728
S729
S730
Liebert iCOM-DO—This parameter shows the connection status of a Liebert iCOM-DO card. It dis-
plays "connected" when a Liebert iCOM-DO card has been set up and connected to the Liebert iCOM
via the CAN bus.
Override—Selecting Override permits manual testing of the Liebert iCOM-DO by activating each
output on the following screen.

Figure 73 iCOM-DO Events Setup - Page 2

iCOM-DO Events Setup (pg 2 of 3)
S731
S732
S733
S734
S735
S736
S737
S738
S739
S740
S741
Status—This column shows whether an output is in a normally closed or normally open state.
Output #—This column shows which output is tied to a particular alarm. The default values are set
to be the same output as the Liebert ENV-DO card, the predecessor to the Liebert iCOM-DO.
ID—This column displays the number of the Liebert iCOM-DO. Currently only one Liebert iCOM-DO
card is supported.
PASSWORD (Actual Level 3)
iCOM-DO #0
Override #0
for next/previous unit
then to change parameter
PASSWORD (Actual Level 3)
Event Description
Cooling Status
Heating Status
Humidifying Status
Dehumidifying Status
High Temperature
High Humidity
Low Temperature
Low Humidity
for next/previous unit
then to change parameter
UNIT 01
connected
to select parameter
to confirm
UNIT 01
ID Output # Status
No 9
No 9
No 10
No 11
No 12
No 13
No 14
No 15
to select parameter
to confirm
83
Service Menu Parameters
????
no
????
0
0
0
0
0
0
1
1
