Figure 66 Set Alarms Parameters Screen; Figure 67 Set Alarms Parameters Screen - Emerson Liebert Challenger 3000 User Manual

Figure 66 Set alarms parameters screen - Page 2
SET ALARMS (page 2 of 7)
S212
S213
S214
S215
S216
S217
S218
S219
S220
S221
S222
Customer Input 1, 2, 3 & 4—These parameters select the device and operation of the customer
inputs. Each event reflects a different alarm and possible action to the unit. Refer to table 7 for a
description of selectable options.
Customer Input 1, 2, 3 & 4 active when—These parameters select whether the input is a normally
closed or normally closed input.
WARNING ACTIVATES ALARM RELAY—This parameter sets the alarm relay (K3) to activate
when a warning occurs.
Water Alarm Shuts Unit Down—This parameter when set will turn the unit off if a water alarm
occurs.
Figure 67 Set alarms parameters screen - Page 3
SET ALARMS (page 3 of 7)
S223
S224
S225
S226
S227
S228
S229
S230
S231
S232
S233
S234
S235
Delay—The delay selection for each alarm
EN-DIS—The enable / disable selection for each alarm provides the ability to individually select the
alarms that will or will not activate when the alarm condition occurs.
PASSWORD (Actual Level 0)
Customer Input 1
Customer Input 1 active when
Customer Input 2
Customer Input 2 active when
Customer Input 3
Customer Input 3 active when
Customer Input 4
Customer Input 4 active when
WARNING ACTIVATES ALARM DELAY
Water Alarm Shuts Unit Down
for next/previous unit
then to change parameter
PASSWORD (Actual Level 0)
MAIN FAN OVERLOAD
LOSS OF AIRFLOW
CLOGGED FILTERS
HIGH ROOM TEMP
LOW ROOM TEMP
HIGH ROOM HUM
LOW ROOM HUM
HIGH TEMP SENSOR A
LOW TEMP SENSOR A
HIGH HUM SENSOR A
LOW HUM SENSOR A
for next/previous unit
th
h
UNIT 01
Water Alarm
Water Alarm
C PMP Alarm
Water Alarm
to select parameter
to confirm
UNIT 01
DELAY EN-DIS TYPE
5 ENABLE
30 ENABLE
2 ENABLE WRN
30 ENABLE WRN
30 ENABLE WRN
30 ENABLE WRN
30 ENABLE WRN
30 DISAB WRN
30 DISAB WRN
30 DISAB WRN
30 DISAB WRN
to select parameter
to confirm
80
Service Menu Parameters
????
Closed
Closed
Closed
Closed
Yes
No
????
ALM
ALM
