Sample Site Inspection Checklist - HP Integrity BL860c i2 User's & Service Manual

Operating
Non-operating
1
All temperature ratings shown are for sea level. An altitude derating of 1°C per 304.8 m (1.8°F per 1000 ft) to 3048
m (10,000 ft) is applicable. No direct sunlight allowed. Upper operating limit is 3,048 m (10,000 ft) or 70 Kpa/10.1
psia. Upper non-operating limit is 9,144 m (30,000 ft) or 30.3 KPa/4.4 psia.
2
Storage maximum humidity of 95% is based on a maximum temperature of 45°C (1 13°F). Altitude maximum for storage
corresponds to a pressure minimum of 70 KPa.
For more information on the c-Class enclosures, go to
cache/316735-0-0-0- 1
For more site preparation information, go to http://www.hp.com/go/Blades-docs, select HP
Integrity BL860c i2 Server Blade in the list of servers, and then select the Generalized Site Preparation
Guidelines.

Sample Site Inspection Checklist

Table 3 Customer and HP Information
Customer Information
Name:
Street address:
State or province:
Zip or postal code:
Primary customer contact:
Secondary customer contact:
Traffic coordinator:
Sales representative
Representative making survey
Scheduled delivery date
Table 4 Site Inspection Checklist
Check either Yes or No. If No, include comment number or date.
Computer Room
Number Area or condition
1. Is there a completed floor plan?
2. Is adequate space available for maintenance needs? Front 36
inches (91.4 cm) minimum and rear 36 inches (91.4 cm) minimum
are recommended clearances.
3. Is access to the site or computer room restricted?
4. Is the computer room structurally complete? Expected date of
completion?
5. Is a raised floor installed and in good condition?
6. Is the raised floor adequate for equipment loading?
7. Are channels or cutouts available for cable routing?
21.htmlf.
HP information
20% to 80%
5% to 95%
http://h71028.www7.hp.com/enterprise/
Phone number:
City or Town:
Country
Phone number:
Phone number:
Phone number:
Order number:
Date:
Yes
Sample Site Inspection Checklist
Comment or Date
No
1 1
