Disk drive blanks

The server blade has two disk drive bays. If you only purchased one hard disk, then your server
blade has a hard drive blank installed. Hard drive blanks maintain proper airflow throughout the
server blade.
CAUTION:
blade without a disk drive or disk drive blank causes improper airflow and cooling, which can
lead to thermal damage.

Removing a disk drive blank

Remove the component as indicated:
To replace the hard drive blank, slide the blank into the bay until it locks into place. The hard drive
blank is keyed to fit only one way.

Disk drives

The BL860c i2 Server Blade has SAS disk drive slots on the BL860c i2 server blade. The SAS disk
drives have identical LEDs that display the drive status.
1 14 Removing and replacing components
Populate hard drive bays with a disk drive or a disk drive blank. Operating the server
