Table 9 Basic Low End Troubleshooting (continued)
Step Condition
2 Server blade does not power on after front panel
power button is momentarily pressed (less than
four seconds).
3a Blade health LED is off and iLO 3 MP is not
running.
3b Blade health LED is flashing amber or red and
iLO 3 MP is running.
4a Cannot see iLO 3 MP prompt on system console
-- blade server power is on. iLO 3 MP is running.
4b Cannot see UEFI prompt on system console. iLO
3 MP is running.
4c Cannot find a boot disk. The iLO 3 MP is running.
Action
4. If the power button's integrated LED on front panel
remains off, then reseat the server blade.
5. As a last resort, replace the server blade. This issue is
fixed when the front panel LED states are as follows: blade
health is steady green.
A fatal fault has been detected and logged, attempting
to power on the server.
1. Examine enclosure power supply LEDs. If they are not
steady green, then replace power supply.
2. If the enclosure power supply LED is green, then you
might need an additional power supply to supply sufficient
power to run the blades in the enclosure.
3. Examine the iLO 3 MP subsystem logs for events related
to DC power rails.
This issue is fixed when the front panel LEDs are as
follows: Health is steady green and power is steady
green.
A fatal fault has been detected and logged while booting
or running system firmware.
1. Cannot access the iLO 3 MP at this time.
2. Must reseat or replace the server blade. This issue is
fixed when the iLO 3 MP logs can be read and both front
panel health LED and server power LED states show:
Flashing green or steady green, and steady green,
respectively.
A warning or critical failure has been detected and
logged while booting or running system firmware.
Examine the iLO 3 MP logs for events related to switched
DC power or cooling fans or configuration. This issue is
fixed when both front panel health LED and server power
LED states show: Flashing green or steady green, and
steady green, respectively.
Nothing can be logged for this condition. The blade
health LED state indicates that the server blade is either
booting or running system FW, or booting or running OS.
1. Look for loose, damaged, or disconnected signal cables
between the system console device, and serial port
connector on the front panel.
2. Be sure that that the RS232C configuration matches
between the server blade and the local console (see
"Troubleshooting the server interface (system console)"
(page 106) for more details).
3. As a last resort, replace the server blade. This issue is
fixed when the iLO 3 MP menu appears on the system
console.
Nothing can be logged for this condition.
1. Examine the iLO 3 MP logs for entries related to
processors, processor power modules, and shared
memory, and core I/O devices (see
logs" (page 101) for more details).
2. As a last resort, replace the server blade. This issue is
fixed when the UEFI menu appears on the system console.
Nothing can be logged for this condition.
1. Reinsert the boot disk into the drive bay
"Errors and error
