B.1 Backplane Options
IPC-623 supports a variety of backplanes, from 18-slot to 20-slot.
Users can contact an Advantech local sales representative for detailed
backplane specification and relevant information.
Model Name
PCA-6120-0B1
PCA-6120P4-0B1
PCA-6119P7-0B1
PCA-6119P17-0B1
PCA-6119P16X
PCA-6120P12-0A1
PCA-6120P18-0A1
PCA-6120D-0B1
PCA-6120DP4-0B1
PCA-6120DP7-0B1
PCA-6120Q-0B1
PCA-6116QP2-0B1

Table B.1: Backplane models

Segment
PICMG
Single
Single
Single
Single
Single
Single
Single
Dual
Dual
Dual
Quad
Quad
Slots Per Segment
PICMG/PCI
-- --
2 --
-- 2
1 1
2 --
1 1
1 1
-- --
4 2
3 --
-- --
7 --
PCI ISA
-- 20
4 14
7 10
16 --
16 1
11 7
17 1
-- 20
6 7
14 1
-- 20
8 1
