- Page 1 IPC-644 Series 4-slot MicroBox IPC Chassis User's Manual...
- Page 2 Copyright Notice This document is copyrighted, May 1999, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
-
Page 3: Table Of Contents
Contents Chapter 1 General Information 1.1 Introduction ............1 1.2 Specifications ............1 1.3 Dimensions ............4 1.4 Mounting .............. 5 1.5 IPC-644 Exploded Diagrams ....... 6 1.6 PCA-6104-B Diagram .......... 7 1.7 PCA-6104NP2 Diagram ........8 Chapter 2 System Setup 2.1 Removing the Top Cover ........ -
Page 4: Chapter 1 General Information
Chapter 1 General Information 1.1 Introduction The IPC-644 MicroBox IPC chassis is an ultra-compact 4-slot mini-node chassis that is ideal for embedded applications. Its small size enables it to fit in mobile environments such as boats, cars and other vehicles. Naturally, indoor operation is equally suitable. -
Page 5: Specifications
1.2 Specifications General • Construction: Heavy-duty steel • Controls: AC power on/off and reset switches • Cooling fans: One 49 CFM filtered cooling fan for inward airflow, and one 14 CFM cooling fan (flow-in) for outward airflow • Mounting: On wall or desktop •... - Page 6 Power supply PS-80 • Output rating: 80 watts maximum • Input voltage: 85 ~ 264 V @ 47 ~ 440 Hz • Output voltage: +5 V @ 8 A, +12 V @ 3.5 A, -12 V @ 1 A • MTBF: 50,000 hours •...
-
Page 7: Dimensions
1.3 Dimensions Unit = mm (inches) IPC-644 User's Manual... -
Page 8: Mounting
1.4 Mounting The IPC-644 can either be wall mounted or desktop mounted. Refer to the figures below for how to install the brackets. Wall mounting Desktop mounting Chapter 1 General Information... -
Page 9: Ipc-644 Exploded Diagrams
1.5 IPC-644 Exploded Diagrams IPC-644 User's Manual... -
Page 10: Pca-6104-B Diagram
1.6 PCA-6104-B Diagram 4 ISA slot backplane Dimensions: 186 x 95 mm Unit = mm Chapter 1 General Information... -
Page 11: Pca-6104Np2 Diagram
1.7 PCA-6104NP2 Diagram 1 ISA / 2 PCI / 1 NLX CPU slot backplane Dimensions: 210 x 110 mm Unit = mm IPC-644 User's Manual... -
Page 12: Chapter 2 System Setup
Chapter 2 System Setup Installation procedures for the IPC-644 are described below. WARNING: Before starting the installation procedures, make sure you disconnect all power from the chassis. Unplug the power cord from the power outlet in the wall. Merely turning off the power switch is not sufficient. -
Page 13: Replacing The Filter
2.2 Replacing the Filter The fan filter is located at the front end of the chassis. Refer to Figure 2-2. 1. Remove the two screws located at the bottom of the filter cover. 2. Detach the filter cover by pulling it downward. 3. -
Page 14: Installing The Fdd And Hdd
2.3 Installing the FDD and HDD The FDD and HDD drive bay is located in the lower deck of the chassis. The upper deck has to be detached first, in order to make the lower deck accessible for installation. Separating the two decks 1. -
Page 15: Figure 2-3: Installing The Fdd And Hdd
Figure 2-3: Installing the FDD and HDD Completing the installation 1. Return the drive bay to its original position and re-attach the screws. 2. Put the upper deck back and secure it with the four screws. 3. Plug the power supply connectors back into the backplane. 4. -
Page 16: Installing The Cards
2.4 Installing the Cards To install slot-board computers and other add-on boards: 1. Remove the chassis cover. Refer to Section 2.1 for further details. 2. Remove the slot cover. 3. Insert the CPU cards or add-on cards vertically and down- ward into the vacant slots. - Page 17 IPC-644 User's Manual...
-
Page 18: Appendix A Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is equal to or less than 55 dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. Appendix A Safety Instructions... -
Page 19: Wichtige Sicherheishinweise
60° C (140° F), weil diesen Temperaturen das Gerät zerstören könten. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 55 dB(A) oder weiger. DISCLAIMER: This set of instructions is provided according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. IPC-644 User's Manual...
