IPC-601-SCA
1U e-Server Chassis

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPC-601-SCA and is the answer not in the manual?

Questions and answers

Summary of Contents for Advantech IPC-601-SCA

  • Page 1 IPC-601-SCA 1U e-Server Chassis...
  • Page 2 Copyright Notice This document is copyrighted, November 2000, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3: Table Of Contents

    Contents Chapter 1 Introduction......1 Introduction..............2 Specifications..............2 Dimensions..............4 Chapter 2 System Setup.......5 Removing the Cover............6 Installing CPU and Add-on Cards.........7 Replacing the Fan............8 Adding Disk Drives............8 Appendix A Passive Backplane..13 Appendix B Alarm Board....15 Appendix C SCA-2 Backplane..17 Appendix D Exploded Diagram..19 Appendix E Safety Instructions..21 English................21 German - Wichtige Sicherheishinweise....
  • Page 5: Chapter 1 Introduction

    Introduction This chapter gives background informa- tion on the IPC-601-SCA. Sections include: • Introduction • Specifications • Dimensions...
  • Page 6: Introduction

    1.1 Introduction The IPC-601-SCA is a 1U high, rack-mount e-Server chassis for high- density internet services. Engineered for service providers and enterpirses, the IPC-601-SCA's rack-mount 1U form factor is best for stacking servers as services grow. The IPC-601-SCA is designed to accommodate PICMG passive backplane and full-sized CPU card configurations to provide flexibility with high reliability.
  • Page 7 Power supply • Output rating: 320 watts max. • Input rating: 115/230 V , 50/60 Hz, auto-switch • Output voltage: +3.3 V @ 20 A, +5 V @ 32A, +12 V @ 12 A, -5 V @ 0.5 A, -12 V @ 0.5 A, +5 Vsb @ 2 A •...
  • Page 8: Dimensions

    1.3 Dimensions Unit: mm Figure 1-1: IPC-601-SCA dimensions IPC-601-SCA User's Manual...
  • Page 9: Chapter 2 System Setup

    System Setup The following procedures are provided to assist you in setting up the IPC-601- Chapter 2 System Setup...
  • Page 10: Removing The Cover

    1. Unscrew the screws at the rear side of the upper cover. 2. Slide the upper cover backwards. 3. Lift up the upper cover. Please refer to the Figure 2-1 below for illustration. Figure 2-1: Upper cover removing IPC-601-SCA User's Manual...
  • Page 11: Installing Cpu And Add-On Cards

    2.2 Installing CPU and Add-on Cards The IPC-601-SCA supports one PICMG full sized CPU card and one PCI add on card. In order to install the CPU card and add-on card, we suggest to take out the tray from the chassis and install the cards in the tray ouside the chassis.
  • Page 12: Replacing The Fan

    The IPC-601-SCA provides one SCA-2 backplane and supports three hot-swap hard disk drives. Please notice that if the hard disk drives used in the IPC-601-SCA shall be 3.5", 1" height SCSI hard disk drives with 80-pin SCA-2 connecotrs.
  • Page 13 Figure 2-4: Hard disk assembled Figure 2-5: Opening the hard drive bay Chapter 2 System Setup...
  • Page 14 Figure 2-6: Hard drive bay fully open Figure 2-7: Putting the hard drives into the hard drive bays IPC-601-SCA User's Manual...
  • Page 15 Figure 2-7: Closing the latches Chapter 2 System Setup...
  • Page 16 IPC-601-SCA User's Manual...
  • Page 17: Appendix A Passive Backplane

    Enabl e / Di sabl e ATX power f unct i on ATX power connect or PCI sl ot PCI expansi on sl ot PI CM G sl ot PI CM G f ul l si z ed CPU car d IPC-601-SCA User's Manual...
  • Page 18 IPC-601-SCA User's Manual...
  • Page 19: Appendix B Alarm Board

    Appendix B Alarm Board Connect or Descr i pt i on Al ar m LED connect or t o LED boar d Fan sensor connect or t o backpl ane PCA- 6102P1V Power connect or t o power suppl y CN10 Tem per at ur e connect or t o t em p.
  • Page 20 IPC-601-SCA User's Manual...
  • Page 21: Appendix C Sca-2 Backplane

    Appendix C SCA-2 Backplane i r c i t c Appendix A Diagrams...
  • Page 22 IPC-601-SCA User's Manual...
  • Page 23: Appendix D Exploded Diagram

    Appendix D Exploded Diagram IPC-601-SCA User's Manual...
  • Page 24 & l i a l i a " 5 " 5 " 5 " 5 d i l f l i " 5 " 5 c i t " 5 IPC-601-SCA User's Manual...
  • Page 25: Appendix E Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is equal to or less than 70 dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 26: German - Wichtige Sicherheishinweise

    Temperaturen das Gerät zerstören könten. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. DISCLAIMER: This set of instructions is provided according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
