Operation Temperature:0°C ~ 40°C (32°F ~ 104°F)

Storage Temperature: -40° to +60°C (-40° to +140°F)

Relative Humidity: 10 ~ 95%@40°C, non-condensing

Vibration (operating): 5Hz ~ 500Hz, 1G rams, 2G(non-operating)

Shock (non-operating): 30 G with 11m Sec duration, 1/2 sine wave

Altitude: 0 to 3048m (0 to 10,000 ft)

Slide Rail:General Device C-300 series supported

Safety: UL, cUL, CE

1.3 Passive Backplane Options

Single System Backplane models (refer appendix for details)

·PCA-6120

·PCA-6120P4

·PCA-6119P7

·PCA-6119P10

·PCA-6119P17

·PCA-6119P16X (16 PCI 64_bit)

Multi-System Backplane models

·PCA-6120D, PCA-6120DP4 (Dual segment)

·PCA-6120Q, PCA-6116QP2 (Quad segment)

Chapter 1 General Information
