- Page 1 IPC-616 14-slot Fault-resilient IPC Chassis User's Manual...
- Page 2 Copyright notice This document is copyrighted, April 2000, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
-
Page 3: Table Of Contents
C o n t e n t s C o n t e n t s C o n t e n t s C o n t e n t s C o n t e n t s Chapter 1 General Information .......... -
Page 4: Chapter 1 General Information
300-watt switching power supply, and hot-swap cooling fans, all in a single compact chassis. A fault detection and alarm notification system is provided in the IPC-616. It monitors its own hard- ware status, including temperature, cooling fans, and power. - Page 5 DC supply system earthing electrode conductor is connected. 2. The IPC-616 is located not only in the same immediate area (such as adjacent cabinets) as any other equipment that has a connection between the earthed conductor of the same DC supply circuit.and the earthing conductor, but also in the same immediate area as the point of earthing of the DC system.
- Page 6 • Relative humidity: 10 ~ 95% @ 40°C, non-condensing • Vibration (operating): 5 ~ 500 Hz, 1 G rms for random vibration • Shock (operating): 10 G acceleration peak (11 msec. duration) • Safety: UL, C-UL approved • CE compliant IPC-616 User's Manual...
-
Page 7: Dimensions
1.3 Dimensions Unit: mm (inches) IPC-616 User's Manual... -
Page 8: Chapter 2 System Setup
Chapter 2 System Setup Setting up your IPC-616 requires only a screwdriver and a small amount of time. Before you begin, you should also gather together all of the cards you plan to install, as well as the keyboard you plan to use. -
Page 9: Removing The Handles
2.3 Adding Your Disk Drives 1. After removing the cover, you will see four screws near the drive bay. Remove these screws. Lift the drive bay free of the chassis. See Figure 2-3 below: Figure 2-3: Removing the screws IPC-616 User's Manual... -
Page 10: The Hold-Down Clamp
Figure 2-4: Assembling the disk drive bay 2.4 The Hold-down Clamp The IPC-616 uses a hold-down clamp to ensure that the plug-in cards are positioned securely. It also offers protection against shock and vibration. To install your cards into the passive backplane, proceed as follows: 1. -
Page 11: Replacing The Filter
2.5 Replacing the Filter The filter is located on the left side of the front panel. If the IPC-616 is under continuous use, the filter should be removed about once a month. To replace the filter, remove the thumbscrew to open out the front panel. -
Page 12: Attaching The Backplane To The Backplane Bracket
The backplane bracket has 29 attaching holes (see Figure 2-9). Any of six backplanes or the Intel L440GX motherboard may be attached to backplane bracket. A table on the bracket shows which holes should be used for each of the backplane/motherboard options. Figure 2-9: Backplane bracket IPC-616 User's Manual... -
Page 13: Chapter 3 Fault-Resilient Functions
Chapter 3 Fault-resilient Functions 3.1 Introduction A fault-resilient IPC has a fault detection and alarm notification system. The IPC-616 monitors its own status. See Figures 3-1 and 3-2 below. When a malfunction occurs, the unit alerts users of the need for maintenance. -
Page 14: Visible And Audible Alarms
3.3 Visible and Audible Alarms The IPC-616 provides quick fault identification with nine front panel LED indicators displaying the system's status as follows: Power failure: If either the backplane power source (+5 V, +12 V, +3.3 V, -5 V, -12 V) or redundant power module fails, the "PWR"... -
Page 15: Appendix A Passive Backplanes
Appendix A Passive Backplanes A.1 PCA-6114P4-B: 9 ISA / 4 PCI / 1 PICMG-slot Backplane Dimensions: 260 x 315 mm Unit: mm IPC-616 User's Manual... -
Page 16: Pca-6113P4R: 8 Isa / 4 Pci / 1 Picmg-Slot Backplane
A.2 PCA-6113P4R: 8 ISA / 4 PCI / 1 PICMG-slot Backplane Dimensions: 260 x 315 mm Unit: mm IPC-616 User's Manual... -
Page 17: Pca-6114P7: 6 Isa / 7 Pci / 1 Picmg-Slot Backplane
A.3 PCA-6114P7: 6 ISA / 7 PCI / 1 PICMG-slot Backplane Dimensions: 300 x 323 mm Unit: mm IPC-616 User's Manual... -
Page 18: Pca-6114P10: 3 Isa / 10 Pci / 1 Picmg-Slot Backplane
ATX power supply power ON PS-ON open ATX power supply power OFF + 5V NAME 1-3,2-4 CLOSED V_IO = +3.3V for sceondary PCI Bus 5V STB 5V STB 3-5,4-6 CLOSED V_IO = +5V for sceondary PCI Bus +12V PS-ON Default : IPC-616 User's Manual... -
Page 19: Appendix B Exploded Diagram And Parts Ordering Guide
Appendix B Exploded Diagram and Parts Ordering Guide B.1 Exploded Diagram IPC-616 User's Manual... -
Page 20: Parts Ordering Guide
B.2 Parts Ordering Guide IPC-616 User's Manual... -
Page 21: Appendix C Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is equal to or less than 70 dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. -
Page 22: German - Wichtige Sicherheishinweise
Temperaturen das Gerät zerstören könten. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. DISCLAIMER: This set of instructions is provided according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
