Chapter 2 System Setup

The following procedures instruct users to install the backplane, add-on
cards, disk drives into the IPC-623 chassis. Please refer to Appendix A,
Exploded Diagram, for all the detailed parts names of IPC-623.
Note: Use caution when installing or operating the components with
the chassis open. Be sure to turn off the power, unplug the power cord
and ground yourself by touching the metal chassis before you handle
any components inside the machine.

2.1 Chassis front and rear section

The IPC-623 is composed of two sections, the front section and the rear
section. Each of them has its own top cover.
The front section includes:
1. A disk drive bay for holding three 5.25" disk drives, one 3.5" FDD
and one internal 3.5" HDD.
2. Three high speed cooling fans.
3. Lockable front door with LED panel.
4. Power supply (dual power supply modules for the Redundant Power
Supply Model; one power supply module for the Single Power Supply
Model). Please see details in section 3.4.
6. Additional disk drive bay for three more 3.5" internal HDD (for the
Single Power Supply Model only). Please see details in section 3.4.
7. There is a pair of ear handles in the accessory box. Users can simply
fasten them to the front right and front left edges of the chassis with
the eight screws provided.
