EasyCoder PX4i and PX6 Service Manual
• Restart the printer and leave the Test Mode.
Refer to the Intermec Shell Overview in Appendix 1 or in the User's
Guide.
If the printer works normally in the Test Mode, it is likely that the mal-
function is either due to communication problems, abnormal conditions at
the site of operation, or a custom-made program.
Returning to Factory Default Setup ( Fingerprint and IPL)
There are four ways to return to the factory default setup of the printer:
Insert a special CompactFlash memory card and restart the printer.
A
Use the Default Setup option in Intermec Shell (Fingerprint only).
B
Use the Memory Reset option in the Test/Service part of the Setup
C
Mode (IPL only).
Use the printer's built-in keyboard as described below:
D
Lift the printhead.
1
Switch on the power to the printer and press the <i> key and wait until
2
the printer beeps.
Swiftly press the following keys:
3
< > < /Esc>
The following message will be displayed:
4
Factory Default?
Enter=Yes ESC=No
Within 10 seconds, press <Enter> to reset the printer to factory default.
5
The parameters will be reset and the printer will continue the normal
startup.
If you press < /Esc> or wait until the 10 seconds time-out has passed,
the normal startup will continue without any reset being performed.
Note: The factory default will remove all fi les used to store settings. It will
not reset settings that already has been read when the fi les are removed.
This means that EasyLAN Wireless settings (SSID, keys, etc.) will retain
their values from the previous start. However, the next reboot will reset
them to factory default.
< /Esc> < >
Chapter 17 — Troubleshooting
211
