Connector Configuration
EasyCoder PX4i and PX6i Service Manual
The IEEE 1284 board has a standard 36pin IEEE 1284 B socket with the
following confi guration:
Pin Signal
1 DSTROBE
2 DATA 0
3 DATA 1
4 DATA 2
5 DATA 3
6 DATA 4
7 DATA 5
8 DATA 6
9 DATA 7
10 ACK
11 BUSY
12 PE
13 SELECT
14 AF
15 N/C
16 GND
17 SCREEN
18
19 GND
20 GND
20 GND
21 GND
22 GND
23 GND
24 GND
25 GND
26 GND
27 GND
28 GND
29 GND
30 GND
31 INIT
32 ERROR
33 N/C
34 N/C
35 N/C
36 SELECTIN
Chapter 16 — Interfaces
Remark
External +5VDC max 500 mA (automatic switch-
off at overload, short-circuit protected)
195
