Chapter 5 — Media Supply
5.3 Three-inch Adapters
3-inch adapter
3-inch adapters
40
One or two adapters (standard accessories) can be fi tted onto the media
supply hub in order to accept media rolls with 76 mm (3 inches) cores.
EasyCoder PX4i has one adapter and EasyCoder PX6i has two. Each
adapter is locked using a #T20 Torx screw. Be careful not to let the screw
hit the leaf springs or the cams of the hub modules.
EasyCoder PX4i and PX6i Service Manual
