How to Connect

Refer to the diagram on page 8 for the location of the sockets identified by numbers in the
following procedures.

Step 1: Connect to the antenna

Connect the antenna lead coming from your antenna wall plate to the ANT IN socket on the
(socket 1).

Step 2: Choose an installation method

There are a number of methods of connecting the , depending on your preference and
the connection types on your TV. These methods are labelled A, B and C below.
TIP: The various video connection options available provide differing degrees of video
quality. In ascending order of quality, these connections are Composite (good),
Component (better) and HDMI (best).

A: High Definition Multimedia Interface

If your TV has a HDMI socket, connect an HDMI cable between the HDMI socket on the
(socket 8) and the HDMI socket on your TV.
A HDMI connection incorporates video and audio. You do not need to make separate connections for
audio.
An HDMI cable is not provided with the .
B: Y/Pb/Pr (Component) using the supplied RCA blue–red–green lead
For Component video, connect to your TV with the supplied Y/Pb/Pr Component cable (with blue, red
and green leads). Connect the leads between the Y, Pb and Pr sockets on the (socket
group 4, taking care to match the colour of a lead with the colour of the socket), and the
corresponding Component sockets on your TV. (The Component sockets on the TV have the same
colour-coding.)
You will need to make separate connections for left and right audio via the audio sockets 5 and 6.
This can be done using the supplied RCA cable. (Match the colour of the plugs with the colour of
the sockets.)
11
