D AF level adjustment
When turning the power ON, a beep is emitted to adjust the
audio frequency level via [VOL].
Select the time period for the beep to 2, 5, 8, 10 (seconds)
or OFF.
AF level 2 (default)
D Favorite channel
Set the Favorite channel function ON or OFF.
The favorite channels are set by the TAG channel setting.
(p. 11)
•
"FAVORITE" scrolls in the channel comment display.
ON : Push the [Y]/[Z] keys on the microphone to sequen-
tially select the favorite channels in the selected chan-
nel group.
OFF : Push the [Y]/[Z] keys on the microphone to sequen-
tially select all channels in the selected channel group.
Scrolls
Favorite channel ON (default)
AF level OFF
Favorite channel OFF
D Remote ID
Set a Remote ID number between 01 and 69.
The Remote ID is included in the sentence of the format for
the Icom original NMEA.
Scrolls
Remote ID 14 (default)
7

SET MODE

1
2
3
4
5
6
7
8
Remote ID 69
9
10
11
12
13
14
15
16
