1.2 Typical System Installation

Figure 1-2
public address system.

1.3 Product Features

Operations Guide
illustrates how the VoIP V2 Loudspeaker Amplifier is normally installed as part of a
Figure 1-2. Typical Installation
802.3af Compliant Ethernet Switch
1 2
Loudspeaker Amplifier
High Power PoE Injector in Box
930360J
3 4 5 6
VoIP Phone
• SIP (RFC 3261) compatible
• Dual-speed ethernet 10/100 Mbps
• Web-based configuration
• Web-based firmware upgradeable
• PoE 802.3at and 802.3af-enabled
• IGMP
• Line-out connector
• DTMF controlled relay with open sense
• Direct speaker drive
• User-uploadable tones
• Simultaneous SIP and Multicast
• Autoprovisioning
• Line-In capability
• Nightringer (can use outbound proxy)
• Weather-resistant NEMA enclosure
• Multiple credentials for registering with
multiple SIP servers
Product Overview
Typical System Installation
SIP Server
