2.2.2 Loudspeaker Amplifier NEMA Box Components
Figure 2-5
Operations Guide
shows all of the NEMA box components of the loudspeaker amplifier.
Figure 2-5. Loudspeaker Amplifier Components—AC powered
930360J
Installing the VoIP V2 Loudspeaker Amplifier
Loudspeaker Amplifier Setup
DIP Switches
RTFM Switch
Ethernet Connection
LEDs
Volume
Speaker Connection
Injector
AC power
