1.2 Typical System Installation

The Voice-over-IP (VoIP) Intercom is a Power-over-Ethernet (PoE 802.3af) and Voice-over-IP (VoIP)
two-way communications device that easily connects into existing local area networks (LANs) with
a single cable connection. The intercom is compatible with most SIP-based IP PBX servers that
comply with SIP RFC 3261.
Figure 1-2
phone system.
Door Strike
.
Operations Guide
illustrates how the VoIP Indoor Intercom with Keypad can be installed as part of a VoIP
Figure 1-2. Typical Installation—Door Entry/Access Control
1
VoIP Intercoms with Keypad
Warning
Electrical Hazard: The VoIP Intercom enclosure is not rated for any AC voltages.
GENERAL ALERT
Warning
Electrical Hazard: This product should be installed by a licensed electrician
according to all local electrical and building codes.
GENERAL ALERT
Warning
Electrical Hazard: To prevent injury, this apparatus must be securely attached to
the floor/wall in accordance with the installation instructions.
GENERAL ALERT
Generic PoE Hub
2 3 4 5 6
930323G
How to Identify This Product
IP Phone
IP PBX Server
CyberData Corporation
Product Overview 2
