CyberData 11113 Operation Manual page 17

Connector
J4
J8
JP0
JP1
JP2
JP3
JP4
JP5
JP6
JP7
JP8
JP9
JP10
JP11
Operations Guide
Figure 2-5. Connector Locations
Table 2-4. Connector Functions
Description
J-Tag
Console
PoE Option
Boot Mode
Boot Mode
Boot Mode
Reset Jumper
WD Enable
Audio Enable
Phy Mode
Phy Mode
Phy Mode
Intrusion Disable Jumper
Option Jumper
930323G
Installing the VoIP Indoor Intercom with Keypad
Function
Factory only.
Factory only
Factory only
Factory only
Factory only
Factory only
Placing a jumper on JP4, and then removing it will cause
the board to reset/reboot.
Not used
Factory only
Not Used
Not Used
Not Used
Placing a jumper on JP10 will disable the intrusion
detection circuit.
Not used
