2.2.3 Identifying the Connector Locations and Functions

See Figure 2-3
and functions.
Connector
J1
J3
SW1
Operations Guide
through Figure 2-5 and Table 2-2
Figure 2-3. Connector Locations
Table 2-2. Connector Functions
Function
PoE Network Connection (RJ-45 ethernet)
Terminal Block (see Figure
RTFM (see Section 2.2.6, "RTFM
930323G
Installing the VoIP Indoor Intercom with Keypad
through Table 2-4 to identify the connector locations
2-1)
Switch")
Parts List
CyberData Corporation
9
