Installing the VoIP Indoor Intercom with Keypad 23
Parts List
Table 2-8. Device Configuration Parameters (continued)
Web Page Item Description
Click on the Test Microphone button to do a microphone
test. When the Test Microphone button is pressed, the
following occurs:
1. The device will immediately start recording 3 seconds of
audio.
2. The device will beep (indicating the end of recording).
3. The device will play back the recorded audio.
Click on the Test Relay button to do a relay test.
Click on the Test Relay button to do a button test. When
pressed, the button text will change to Stop Button Test
and in this mode, pressing the button will play test audio.
Also, pressing this button also puts the device into a mode
where it will play audio as the buttons are pressed. For
buttons 0-9 it will play the audio file for that number. For
buttons '*', '#', and the Call Button, it will play the
appropriate DTMF tones.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
3. After changing the parameters, click the Save button.
